BodyGuardian One – Instructions for Use 4
2 Attach electrodes to lead wires
Complete the following steps to attach the electrodes:
1. Snap one ECG electrode into each of the five colored leads.
3 Attach to your chest
1. Remove the adhesive backing from each of the electrodes, then attach them to your
chest:
2. Attach the LA - BLACK lead.
Remove the adhesive backing from the
electrode.
Attach aligned with the left side of the neck,
two to three inches below the left
3. Attach the LL - RED lead.
Apply electrodes only to intact, clean skin. Do not apply over open wounds, lesions,
infected, or inflamed areas. If you have skin allergies or hypersensitivities to
adhesives, consult your doctor to select the appropriate option.
