PREVOST Le Mirage XL User Manual

CONTROLS/INSTRUMENTS
2 - 33
Spare Parts Kit (optional)
A Spare Parts Kit may be supplied with your vehicle. Parts are stored in a cardboard box located inside
the forward baggage compartment.
Kit contents depend on certain vehicle options as shown below:
1 = Series 60 Engine + Driver's A/C System + 24V-75A Alternator.
2 = Series 60 Engine + Driver's A/C System + 24V-75A Alternator + 12V-145A Alternator.
3 = Series 60 Engine + Driver's A/C System + 24V-270A Alternator.
4 = Series 60 Engine + Driver's A/C System + 12V-145A Alternator + 24V-270A Alternator.
5 = Series 60 Engine + Full A/C System + 24V-270A Alternator.
6 = Series 60 Engine + Full A/C System + 12V-145A Alternator + 24V-270A Alternator.
7 = Series 60 Engine + Driver's A/C System + 12V-300A Alternator + 24V-75A Alternator.
Part No. Description QTY Option No.
1 2 3 4 5 6 7
561122 Light Bulb, 24V 2 X X X X X X X
561166 Light Bulb #464, 24V, 3W 2 X X X X X X X
562278 Light Bulb, 24V, 10W 4 X X X X X X X
561707 Relay, 24V 1 X X X X X X X
561797 Circuit Breaker, 3 Amp 1 X X X X X X X
561790 Circuit Breaker, 6 Amp 1 X X X X X X X
561791 Circuit Breaker, 8 Amp 1 X X X X X X X
561792 Circuit Breaker, 10 Amp 1 X X X X X X X
561793 Circuit Breaker, 15 Amp 1 X X X X X X X
561794 Circuit Breaker, 20 Amp 1 X X X X X X X
561795 Circuit Breaker, 25 Amp 1 X X X X X X X
561880 Light Bulb, 12V, 21W 3 X X X X X X X
561881 Light Bulb, 12V, 10W 2 X X X X X X X
561882 Light Bulb, 12V 1 X X X X X X X
451144 Gauge, Oil 1 X X X X X
506680 V-Belt, BX-80 1 X X
506685 V-Belt, A35 1 X X X X X
506690 V-Belt, AX-74 3 X X X X X X X
506688 Belt, Multi-V 1 X X X X X X X
506681 V-Belt, BX-100 1 X X

PREVOST Le Mirage XL Specifications

General

Category	Motorhomes
Manufacturer	Prevost
Model	Le Mirage XL
Length	45 ft
Height	12.5 ft
Engine	Detroit Diesel Series 60
Transmission	Allison 6-speed automatic
Fuel Type	Diesel
GVWR	54, 000 lbs
Horsepower	500 hp
Width	102 in
Fuel Capacity	200 gal
Sleeping Capacity	6
