VII. COMFORT ADJUSTMENTS
Figure 16B. Armrest Angle Adjustment
ARMREST
ADJUSTMENT
DIAL
METAL TAB
PLASTIC
HOUSING
Figure 16C. Positioning Belt
ARMREST ANGLE ADJUSTMENT
There is an armrest adjustment dial on the underside of
each armrest. To adjust the armrest angle while seated in
your scooter turn the armrest adjustment dial to the left to
lower the armrest angle or to the right to raise the armrest
angle.
NOTE: The armrests also pivot upward to make getting
on and off of your scooter easier.
POSITIONING BELT
Your scooter seat may be equipped with an automotive
positioning belt that can be adjusted for operator com-
fort. See figure 16C. The positioning belt is designed to
help support the operator so that he or she does not slide
down or forward in the seat. The positioning belt is not
designed for use as a restraining device.
To install the positioning belt (if required):
1. Remove the seat from your scooter.
2. Place the seat upside down so that you can see the
bottom of the seat base.
3. Using a 5-mm hex key, remove the two bolts on the
outermost part of the rear seat mounting strap.
4. Insert the bolt through the appropriate end of the po-
sitioning belt and then through the seat mounting strap
for each side of the scooter seat.
5. Tighten the bolts.
To adjust the positioning belt for operator comfort:
1. Insert the metal tab on the right side of the belt into
the plastic housing on the opposite strap until you hear
a “click.”
2. Pull the strap on the right side of the belt until it is
secure, but not so tight as to cause discomfort.
