Mid-size Scooter Series 27
EN
V. COMFORT ADJUSTMENTS
NOTE: Pivot the armrests upward to aid in getting onto and
off of your scooter.
Seat Rotation Adjustment
The seat rotation lever will secure the seat into several positions.
1. Depending on your seat type, either pull upward or push
forward on the seat rotation lever to disengage the seat. See
fi gure 19 or 20.
2. Rotate the seat to the desired position.
3. Release the lever to secure the seat into place.
Seatback Adjustment
WARNING! Do not operate your scooter with
the seatback in a reclined position.
WARNING! Always keep your back pressed
fi rmly against the seatback while adjusting the
angle.
If your scooter is equipped with a reclining seatback, you can
adjust the seatback angle with the seatback adjustment lever.
See fi gure 20.
1. With your back pressed up against the seatback, lift up on
the seatback adjustment lever and lean forward or rearward
to adjust the seatback angle.
2. Release the seatback adjustment lever once the seat is in a
comfortable riding position.
IDENTIFICATION KEY
1. SEATBACK ADJUSTMENT LEVER
2. SEAT ROTATION LEVER
3. SEAT SLIDING LEVER
4. ACCESSORY BRACKET
5. DETENT PIN
Figure 20. Seat Adjustments – Style B
1
2
3
4 5
Front-to-back Seat Adjustment
If your scooter is equipped with an adjustable seat, you can reposition the seat forward or rearward to adjust the
distance between the seat and the tiller.
1. Move the seat sliding lever (located at the lower left side of the seat) outward. See fi gure 20.
2. While holding the lever out, slide the seat forward or rearward.
3. Release the seat sliding lever once the seat is in the desired position.
Armrest Angle Adjustment
Armrest angle of your scooter can be adjusted upwards or downwards by turning the adjustment. See fi gure 20.
NOTE: The armrests also pivot upward to make getting on and off of your scooter easier.
Accessory Bracket
The rear-mounted accessory bracket allows you to attach a personal accessory such as a basket, walker holder,
or oxygen tank to the back of your scooter. Utilize the detent pin to securely mount your item to the accessory
bracket. See fi gure 20. See your authorized Provider for details.
