30 Mid-size Scooter Series
EN
V. COMFORT ADJUSTMENTS
Figure 23. Positioning Belt Bolts
A
B
POSITIONING BELT (OPTIONAL)
Your scooter seat may be equipped with a positioning belt that can be adjusted for operator comfort. See fi gure 23.
The positioning belt is designed to help support the operator so that he or she does not slide down or forward in
the seat. The positioning belt is not designed for use as a restraining device.
WARNING! The positioning belt is not designed for use as a seat belt in a motor vehicle. Nor is
your scooter suitable for use as a seat in any vehicle. Anyone traveling in a vehicle should be
properly belted into seats approved by the vehicle manufacturer.
WARNING! The positioning belt should be secured at all times. Never allow the positioning belt
to hang or drag on the fl oor as it may become entangled.
Seat Suspension Adjustment (if available)
You can loosen or stiff en the seat suspension based on which comfort spring you install.
To adjust the seat suspension:
1. Remove the seat from your scooter. Push forward or pull upward and hold the seat rotation lever to disengage the
seat, then rotate the seat and lift it off of the scooter.
2. Remove the rear shroud.
3. Push up the seat post boot to uncover the hardware.
4. Push down on the seat post while loosening and removing the hex head bolt and nut.
5. Remove the current spring.
6. Install the desired spring. See fi gure 22.
7. Press down on the seat post while reinstalling the hardware and tightening to 210 in • lb (24 N • m).
8. Replace the rear shroud and the seat.
