Pride Jazzy Select 6 - The Jazzy Select Power Base; The Jazzy Select 6 Power Base

18 www.pridemobility.com Jazzy Select Series
III. YOUR POWER CHAIR
Figure 7. The Jazzy Select 6 Power Base
MAIN CIRCUIT BREAKER
XLR OFF-BOARD CHARGER HARNESS CONNECTOR
Figure 6. The Jazzy Select Power Base
REAR SHROUD
SEAT POST
MAIN CIRCUIT BREAKER
FRONT COVER
CONTROLLER HARNESS
XLR OFF-BOARD CHARGER HARNESS CONNECTOR
REAR SHROUD
CONTROLLER HARNESS
FRONT COVER
ANTI-TIP WHEELS
CASTER
FRONT CASTERS
CASTER
