46 www.pridemobility.com Jazzy Select Series
APPENDIX I - SPECIFICATIONS
JAZZY SELECT SERIES SPECIFICATIONS
Suspension: Jazzy Select : Active-Trac
Jazzy Select 6 and Jazzy Select 6 Ultra: Active-Trac with Mid-Wheel 6 Technology
Drive Wheels: 10 in. (25.4 cm), solid
Caster Wheels: Jazzy Select: 6 in. (15.24 cm), solid, rear-mounted
Jazzy Select 6 and Jazzy Select 6 Ultra: 6 in. (15.24 cm), solid, front- and rear-mounted
Anti-tip Wheels Jazzy Select only: 5 in. (12.7 cm), solid, front-mounted
Maximum Speed:
1
Up to 4.0 mph (6.44 km/h)
Range:
1
Up to 15 miles (24.14 km)
Brakes: “Intelligent Braking” electronic regenerative, disc park brake
Ground Clearance:
2
Jazzy Select: See figure 31.
Jazzy Select 6 and Jazzy Selelct 6 Ultra: See figure 32.
Maximum Safe Slope: 6° (10.5%)
Turning Radius:
2
Jazzy Select: See figure 31.
Jazzy Select 6 and Jazzy Select 6 Ultra: See figure 32.
Overall Size:
2
Jazzy Select: See figure 31.
Jazzy Select 6 and Jazzy Select 6 Ultra: See figure 32.
Drivetrain: Jazzy Select: Two motor, Mid-wheel drive
Jazzy Select 6 and Jazzy Select 6 Ultra: Two motor, Mid-wheel-6 drive
Batteries:
3
Two 12-volt, U-1 batteries
Battery Charger: 3-amp, off-board
Weight Capacity: 300 lbs. (136 kg)
Component Weights: Jazzy Select Base: 90 lbs. (40.82 kg)
Jazzy Select 6 Base: 100 lbs. (45.36 kg)
Jazzy Select 6 Ultra Base: 112 lbs. (50.8 kg)
Standard Seat: 37 lbs. (16.78 kg)
Batteries: 24.5 lbs. (11.11 kg) each
¹ Varies with base model, user weight, terrain type, battery amp hour rating (Ah), battery charge, battery condition,
motors, controller type, tire type, and tire condition.
² Due to manufacturing tolerances and continued product improvement, this specification can be subject to variance of
(+ or – ) 3%.
³ AGM or Gel-Cell type required. See VI. “Batteries and Charging.”
NOTE: All specifications subject to change without notice.
