NOTE: It is important that the armrest be lifted
straight up prior to securing the controller harness
with wire-ties.
MANDATORY! Prevent controller
harness damage! Avoid routing the
controller harness on the outside of the
armrest pad. Route the harness under
the armrest or toward the inside of the
armrest pad. Use correct tie-down
points for the controller harness to
prevent the harness from getting
caught in the drive tires, pinched in the
seat frame, or damaged when passing
through doorways.
6. Plug the controller harness into the connector on the
power base. See figure 8.
NOTE: Refer to V. “Comfort Adjustments” for more
information on controller installation and adjustment.
WIRE
TIES
Figure 18. Select 6 Ultra Controller Routing
Figure 17. Power Seat Actuator
IV. ASSEMBLY
Figure 16. Seat Latch Safety (Disengaged)
