Jazzy Select Series www.pridemobility.com 41
VII. CARE AND MAINTENANCE
Figure 30. Battery Installation (Seat Removed for Clarity - Select 6 Shown)
CORRECT
CONNECTION
INCORRECT
CONNECTION
REAR SHROUD
FRONT COVER
SIDE COVER
FRONT
BATTERY
REAR
BATTERY
YELLOW
THUMBSCREWS
