22 Rally
TILLER ANGLE ADJUSTMENT
You can adjust the tiller to many positions. The tiller
adjustment lever locks the tiller in place. It has a spring-
loaded mechanism that enables you to rotate it and
change its position.
1. Turn the tiller adjustment lever counterclockwise until
it is loose. If the tiller adjustment lever comes in contact
with the tiller basket, pull it outward, turn it clockwise,
and release it. Continue to loosen until the tiller is able
to move. See figure 10.
2. Move the tiller to a comfortable position.
3. Turn the tiller adjustment lever clockwise until it is
tight. If the tiller adjustment lever comes in contact
with the tiller basket, pull it outward, turn it
counterclockwise, and release it. Continue to turn
the lever until it is tight. The tiller may be lowered
to the center of the floorboard and locked in place
for storage. See VIII. Disassembly and Assembly.
SEAT HEIGHT ADJUSTMENT
The seat can be repositioned to one of three different
heights. See figure 11.
1. Remove the seat from your Rally. See VIII.
Disassembly and Assembly.
2. Use the attached ring to pull and remove the ball
detent pin from the lower seat post.
3. Raise or lower the upper seat post to the desired
seat height.
4. While holding the upper seat post at that height,
match up the holes in the upper seat post and in the
seat post tower.
5. Fully insert the ball detent pin.
6. Replace the seat.
VII. COMFORT ADJUSTMENTS
Figure 11. Seat Height Adjustment
SEAT POST TOWER
SEAT PEDESTAL
LOCATING HOLES
BALL DETENT PIN
Figure 10. Adjusting the Tiller Angle
TILLER ADJUSTMENT LEVER
RELEASE
BUTTON
SLIDE LEVER OUT
TO REPOSITION
WARNING! Remove the key before
adjusting the tiller or the seat. Never
attempt to adjust the tiller or the seat while
the Scooter is in motion.
