TECHNICAL SPECIFICATION
Output power per channel 120W into 8V, 200W into 4V
Output impedance <0.03Ω
Line inputs 1V for 120W into 8Ω
Input impedance 10kΩ
Frequency response <10Hz – 100kHz, -3dB
THD <0.08%
Signal-to-noise, line -100dB
Power consumption 1000W
Dimensions (WxDxH) 430 x 385 x 100mm
Weight ???
