R35 Phono Preamplifier User Guide
8
The following diagram explains the function of each of the
connectors on the back panel:
BACK-PANEL CONNECTIONS
TRIG
MC GAIN
RCA / XLR
62 / 68
66 / 72
70 / 76
MM GAIN
RCA / XLR
36 / 42
40 / 46
44 / 50
MM/MCSUBSONIC FILTER
ON
GND
MM
MC SERVICE
ON
OFF
RR R LL L
IN
OUT
MCMM
ANALOG OUT
ANALOG IN
78910 6 5 4 3 2 1
Subsonic
filter
MM/MC
selector
Gain
selector
Service
input *
Analogue
inputs
Ground
terminal
Impedance/
capacitance
settings R
Balanced
output R
Balanced
output L
Unbalanced
outputs
Impedance/
capacitance
settings R
(cover removed)
Trigger
in/out
Power
and fuse
On/off
MC
ON
MM
1 2 3 4 5 6 7
8 9 10
* The SERVICE input is a 3.5 mini-jack for use by an
authorized dealer or service technician to update or
service the R35.
