15
LAYOUT
Cutting Thickness Chart
Need to adjust the current and air pressure properly under metal thickness to get best cutting
surface
1
CT520 (220V) 20Amps 30Amps 40Amps 50Amps
Thickness (mm) 4mm 6mm 10mm 14mm
Air Pressure (psi) 40psi 50psi 60psi 70psi
Tip size φ0.8-φ0.9 φ0.8-φ0.9 φ0.9-φ1.0 φ0.9-φ1.0
2
CT520 (110V) 25Amps 35Amps
Thickness (mm) 4mm 6mm
Air Pressure (psi) 40psi 50psi
Tip size φ0.8-φ0.9 φ0.8-φ0.9
Accessories
Following accessories come with machine
1. machine x 1
2. plasma cutting torch x 1
3. earth clamp with cable x 1
4. air hose x 1
5. cutting torch tip x 2
6. cutting torch electrode x 2
7. Air regulator x 1
8. Power plug wire adaptor x 1
9. TIG torch * 1
10. Arc holder with cable *1
