Primus ECM Series - Page 14

ECM-SERIES 12
User’ Guide
ECM-13000
WALL TYPE
TECHNICAL SPECIFICATION
MODEL
UNITS
ECM-13000 ECM-13000
SUS
Supply Voltage V-Ph-Hz
Cooling Capacity L35L35 W 3800
Cooling Capacity L35L50 W 2700
Cooling Capacity BTU/h 13000
Dimension
(Width/Height/Depth)
mm 505/1230/370
Max Running Current A 8.8
Start Current A 38
Start Delay Time (D1) min.
Sensor Delay Time (D2)
min.
Recovery Time (D3) min.
Condensor Fan Air Flow m
3
/h 1231
Evaporation Fan Air Flow m
3
/h 1891
Condensor Fan Power
Consumption/Current
W/A 189/0.94
Evaporation Fan Power
Consumption/Current
W/A 189/0.94
Internal Temperature Limits
o
C
Outter Temperature Limits
o
C
Internal Protection Degree IP
External Protection Degree IP IP34
Protection
System
Clot Water Pipe
√
Compressor
√
Refrigerant Charge kg 1
Refrigerant R
Noise Level (Max) dB 75.0
Weight kg 92
1-60 (Default 3 minute)
1-60 (Default 1 minute)
1-60 (Default 1 minute)
25-45
20-55
IP54
134a
220-240/1/(50/60Hz)
Material
-
Steel SUS304
