Primus ECM Series - Page 15

13 ECM-SERIES
User’ Guide
ECM-4000
TOP TYPE
TECHNICAL SPECIFICATION
MODEL
UNITS
ECM-4000 ECM-4000
SUS
Supply Voltage V-Ph-Hz
Cooling Capacity L35L35 W 1400
Cooling Capacity L35L50 W 1170
Cooling Capacity BTU/h 4000
Dimension
(Width/Height/Depth)
mm 604/360/450
Max Running Current A 4
Start Current A 17
Start Delay Time (D1) min.
Sensor Delay Time (D2)
min.
Recovery Time (D3) min.
Condensor Fan Air Flow m
3
/h 367
Evaporation Fan Air Flow m
3
/h 675
Condensor Fan Power
Consumption/Current
W/A 87/0.44
Evaporation Fan Power
Consumption/Current
W/A 62/0.28
Internal Temperature Limits
o
C
Outter Temperature Limits
o
C
Internal Protection Degree IP
External Protection Degree IP IP34
Protection
System
Clot Water Pipe
√
Compressor
√
Refrigerant Charge kg 0.6
Refrigerant R
Noise Level (Max) dB 67.0
Weight kg 50
1-60 (Default 3 minute)
1-60 (Default 1 minute)
1-60 (Default 1 minute)
25-45
20-55
IP54
134a
220-240/1/50Hz
Material
-
Steel SUS304
