Princeton LCD17D - Display Modes

9
Display Modes
Item Resolution Type H. Scan V. Scan Pol. Pixel
(KHz) (Hz) (MHz)
1 640X350 VGA 31.469 70.087 + / - 25.175
2 720X400 VGA 31.469 70.087 - / + 28.322
3 640X480 VGA 31.469 59.940 - / - 25.175
4 640X480 VESA72 37.861 72.809 - / - 31.500
5 640X480 VESA75 37.500 75.000 - / - 31.500
6 800X600 SVGA 35.156 56.250 + / + 36.000
7 800X600 SVGA 37.879 60.317 + / + 40.000
8 800X600 VESA72 48.077 72.188 + / + 50.000
9 800X600 VESA75 46.875 75.000 + / + 49.500
10 1024X768 VESA60 48.363 60.004 - / - 65.000
11 1024X768 VESA70 56.476 70.069 - / - 75.000
12 1024X768 VESA75 60.023 75.029 + / + 78.750
13 1152X864 VESA 67.5 75.0 + / + 108.0
14 1280X960 VESA 60.0 60.0 + / + 108.0
15 1280X1024 VESA 64.3 60.0 + / + 108.0
16 1280X1024 VESA 80.0 75.0 + / + 135.0
