10
Specifications
LCD Display
17.0” TFT Active Matrix Panel
Display Size
337.9(H) x 270.3(V) mm
Pixel Pitch
0.264(H) x 0.264(V) mm
Display Mode
VGA 640 x 350 (70 Hz)
VGA 720 x 400 (70 Hz)
VGA 640 x 480 (60/72/75 Hz)
SVGA 800 x 600 (56/60/72/75 Hz)
XGA 1024 x 768 (60/70/75 Hz)
SXGA 1280 x 1024 (60/75 Hz)
Max. Resolution
SXGA 1280 x 1024
Contrast Ratio
400 : 1
Brightness
300 Cd/m
2
Response Time
25 ms
Display Color
16.2 Million Colors
Viewing Angle
150
o
(L/R), 125
o
(U/D)
Input Signal Video
R.G.B. Analog 0.7V
peak-peak
Sync
TTL Positive or Negative
Signal Connector Analog
15 Pin D-Sub
Digital
24 -pin DVI
Front Control
Power Switch, Menu/Select (up, down), Adjust (+, -)
OSD
Brightness, Contrast, H-Position, V-Position, Auto Tune,
Language, Volume, Frequency, Phase, Red/Green/Blue,
Color Temp, Recall
Plug & Play
DDC1 / 2B
Audio System
1W / Per Channel
