Epson FX Emulation
Page 3-26
m DPI Graphics ESC * m n1 n2 data
Selects eight wire graphics of density m as listed in the following table for n1 + (n2 x
256) columns of data.
m Density _______
0 60 dpi (same as ESC K)
1 120 dpi (same as ESC L)
2 120 dpi high speed (same as ESC Y)
3 240 dpi high speed (same as ESC Z)
4 80 dpi
5 72 dpi
6 90 dpi
7 144 dpi
Example: The following escape sequence will print four bytes of graphics data at 72
x 72 dpi. The resulting figure will resemble a square, since the horizontal and vertical
density are the same. If some other density is chosen, the figure will resemble a
rectangle.
Escape Sequence: ESC * 5 4 0 < < < <
Hexadecimal: 1B 2A 05 04 00 3C 3C 3C 3C
