CONTROL PANEL
6
Main Controls:
Power – On/Off Switch
Dimmer Control – Dim LED Lights as Needed
Connection to Reel – Input Cat 6 Patch Cord
Video Output – Input any monitoring device
Sonde – Turn on to activate 512 Hz Sonde
Power Cord – Plug into 110-240 Volt grounded outlet
Inductive Locator Connection – Used to energize high
tension inspection cable – see locator manual if
applicable.
Digital Footage Counter Controls (optional depending on
model purchased)
.
