17/55
2.7.3 CF Card Interface
(only when using “Multi Unit” (GP077-MLTS11, GP077-MLTE41))
GP-4501T/TW is not equipped with a CF card slot. But a SD card slot and a USB
interface are installed. In order to use the GP-477RE data saved in the CF card and
the functions using the CF card with using Multi Unit (GP077-MLTS11,
GP077-MLTE41), use a SD card or a USB flash drive instead.
* When using a SD card with GP-4501T/TW, please verify it supports the following
specifications:
For the GP-PRO/PBIII’s “CF Card output folder” setting, when project file is
converted on GP-Pro EX, the setting will automatically change to the one that uses
a SD card.
To change the setting of the output destination folder, see [5.1 Changing the
setting of the external media to use].
(The sound output function of the Multi Unit (GP077-MLTS11, GP077-MLTE41)
cannot be used for GP-4501T/TW.)
2.8 Peripheral units and option units
2.8.1 Barcode reader connection
GP-4501T/TW is not equipped with a tool port. A barcode reader that used to be
connected to the tool port on GP-477RE cannot be used. However, GP-4501T/TW
allows you to connect a barcode reader on its USB interface (Type A) or its serial
interface.
For the models GP-4501T/TW supports, see [OtasukePro!]
(http://www.pro-face.com/otasuke/qa/3000/0056_connect_e.html).
To Next Page
