19/55
2.9.2 DC power supply type
The power connector on GP-4501T/TW (DC type) is a spring lock type.
If you replace GP-477RE (DC type) with GP-4501T/TW (DC type), change the
power cable.
2.10 Backup Battery
Unlike GP-477RE, GP-4501T/TW does not use rechargeable secondary batteries but
replaceable primary ones. (For both a rechargeable type and a replaceable one,
contents to be backed up are the same.)
When the time for replacement of backup batteries approaches, the message to urge
you to replace the battery, “RAAA053: Running out of power in the backup battery.
Please change the battery.” appears. When the message appears, replace the battery
referring to the GP4000 series hardware manual.
2.11 Power Consumption
The power consumption of GP-477RE is different from that of GP-4501T/TW.
44VA or less (AC100V)
58VA or less (AC240V)
For the detailed electric specifications, see the hardware manual.
Replaceable Battery Model
