5. Hold the Right Upright (76) against the Base
(74).
Insert a 3/8" x 3 1/4" Screw (2) with a 3/8" Star
Washer (3) into the top hole in the Right Upright
(76). Partially tighten the Screw into the Base
(74).
Partially tighten two more 3/8" x 3 1/4" Screws
(2) with two 3/8" Star Washers (3) into the Right
Upright (76) and the Base (74);
Note: There are no wires on the left
side.
3
76
3
2
74
63
5
4. Lay the Right Upright (76) near the Base (74) as
shown. Attach the ground wire to the Base with a
#8 x 1/2" Ground Screw (1).
Then, press the Upright Grommet (73) into the
square hole in the Right Upright (76).
74
76
1
73
Square
Hole
Ground
Wire
4
To Next Page
