Pro-Form PFEX21020-INT.0 User Manual

8
5. Orient the Rear and Front Upright Covers
(19, 20) as shown.
Press the Rear and Front Upright Covers (19, 20)
together around the Upright (4), and join them
with two M4 x 12mm Screws (57).
Then, press the Rear and Front Upright Covers
(19, 20) downward onto the Left and Right
Shields (21, 22). Attach the Rear Upright Cover
with two M4 x 15mm Flat Head Screws (13).
5
19
20
21, 22
57
13
4
6
42
42
6
4
6. Orient the Handlebar (6) as shown.
Attach the Handlebar (6) to the Upright (4) with
four M8 x 18mm Screws (42); start all the
Screws, and then tighten them.
42
57
13
