11
21
B
12. Identify the Right Pedal (21).
Using an adjustable wrench, firmly tighten the
Right Pedal (21) clockwise into the Right Crank
Arm (19).
Firmly tighten the Left Pedal (not shown)
counterclockwise into the Left Crank Arm
(not shown). IMPORTANT: You must turn the
Left Pedal counterclockwise to attach it.
Then, attach the right pedal strap (B) to the Right
Pedal (21) as shown. Attach the left pedal
strap (not shown) in the same way.
19
12
11
28
27
6
11. Loosen the Seat Post Knob (27) and pull it out-
ward. Then, remove and discard the shipping
bracket (not shown) that is inside the Seat
Post Sleeve (28).
Next, insert the Seat Post (6) into the Seat Post
Sleeve (28), and release the Seat Post Knob
(27). Move the Seat Post upward or down-
ward slightly to make sure that the Seat Post
Knob is engaged in one of the adjustment
holes in the Seat Post. Then, tighten the Seat
Post Knob.
