M8 Nylon Locknut (78)M10 Nylon Locknut (77)
M6 Washer (81)
M8 Washer (83)
M4 Washer (84)
M10 Washer (80)
M10 x 82mm Button Bolt (93)
M10 x 87mm Button Bolt (94)
M8 x 53mm Bolt (9)
M8 x 20mm Button Screw (16)
M8 x 10mm Set Screw (62)
M6 x 63mm Button Screw (92)
M6 x 15mm Button Screw (17)
M4 x 16mm Self-tapping Screw (91)
M10 x 50mm Bolt (79)
M10 x 45mm Bolt (75)
M10 x 82mm Bolt (85)
M10 x 78mm Bolt (87)
M10 x 67mm Bolt (86)
M10 x 20mm Bolt (89)
M10 x 25mm Bolt (88)
M10 x 63mm Button Bolt (90)
M10 x 58mm Button Bolt (95)
M10 x 100mm Screw (26)
PART IDENTIFICATION CHART
R
efer to the drawings below to identify small parts used in assembly. The number in parentheses by each draw-
ing is the key number of the part, from the PART LIST in the center of this manual.
Note: Some small parts
may have been pre-attached. If a part is not in the parts bag, check to see if it has been pre-attached. If
a part is missing, call toll-free 1-888-533-1333.
