7
1. Make sure that the power cord is unplugged.
With the help of a second person, carefully tip
t
he treadmill onto its left side. Have a second
person hold the treadmill to prevent it from
t
ipping. Do not pivot the Frame (45).
Attach the four Base Feet (67) to the Base (62)
in the locations shown with four #8 x 3/4" Tek
Screws (7).
1
45
62
2. Attach a Wheel (66) to the Base (62) with a 3/8"
x 1 1/2" Bolt (4) and a 3/8" Jam Nut (8) from the
direction shown. Do not overtighten the Jam
Nut; the Wheel must turn freely.
Remove the tie holding the Upright Wire (91) to
the Base (62).
2
4
8
66
91
62
Tie
7
7
67
67
7
7
67
6
7
To Next Page
