2 For technical questions call 1-800-665-8685
8475006
V 1.6
60 Gallon
Single Stage Stationary
Air Compressor
SPECIFICATIONS
Air Delivery 18.1 CFM @ 90 PSI
20.6 CFM @ 40 PSI
Air Tank Capacity 60 Gallons (227 litres)
Max. Air Pressure 155 PSI
Cut-In Pressure 125 PSI
Cut-Out Pressure 155 PSI
Compressor Type Belt Driven, Single Stage
Pump Style Cast iron, 3 cylinder, oil-lubricated
Current Rating
24A
Voltage Rating
230V
Noise Rating 81.45 dB
INTRODUCTION
The 60 Gallon Air Compressor has a high flow, single stage pump capable of 18 cubic feet per
minute at 90 PSI. The motor is wired for 230 volt application and features TOPS
®
(Thermal
Overload Protection System) that protects the motor from voltage fluctuations.
The pump is constructed of cast iron with a uniquely designed metal guard that improves
compressor pump cooling. The pump has three cylinders, a one-piece cast iron crankcase, full cast
iron cylinder body, Swedish stainless steel flex leaf valves and a 16 in. cast iron flywheel with large
intake filter/silencers. The low vertical profile 60 gallon ASME air receiver evenly distributes the
weight, making this unit less top heavy than traditional verticalcompressors.
The pump ships with synthetic oil for optimum performance and long life.
