60 Gallon Single Stage Stationary Air Compressor
15Visit www.princessauto.com for more information
8475006
V 1.6
PARTS BREAKDOWN
TORQUE CHART – COMPRESSOR
1 Torque 10.8 to 15 ft-lb (14.7 to 20.3 N-m)
2 Torque 50 to 75 ft-lb (67.8 to 101.7 N-m)
3 Torque 1.7 to 2.5 ft-lb (2.3 to 3.4 N-m)
4 Torque 3.8 to 5.4 ft-lb (5.1 to 7.3 N-m)
5 Torque 7.1 to 7.5 ft-lb (9.6 to 10.2 N-m)
6 Tighten compression nut hand tight plus 1 full turn.
