pro.point 8475006 - Compressor Parts List

60 Gallon Single Stage Stationary Air Compressor
16
For technical questions call 1-800-665-8685
8475006
V 1.6
PARTS LIST – COMPRESSOR
PART # DESCRIPTION QT Y. PART IDENTIFIER
1 Bracket 1 114-0825
2 Screw #10 x 3/4 in. 1 061-0005
3 Belt Guard (Outer) 1 125-0196
4 Set Screw, 5/16-18 2 061-0238
5 Belt 1 007-0077
6 Pulley 1 006-0148
7 Screw, 3/8-16 x 3/4 in. 4 059-0614
8 Belt Guard 1 125-0255
9 Motor 1 160-0338
9A
Start Capacitor 1 166-0191
9B
Run Capacitor 1 166-0178
9C Run Capacitor 1 166-0137
9D Run Capacitor Cover 1 166-0194
9E Capacitor Cover 1 166-0205
10 Key 1 146-0016
11 Bolt, 3/8-16 x 1-1/2 in. 4 059-0380
12 Washer 3/8 in. 16 060-0023
13 Nut, 3/8 in. 8 058-0009
14 Strain Relief 1 071-0002
15 Interconnect Cord 1 026-0836
16 Tank Assembly, 60 Gallon (Includes Items
16A-16D)
1 S021-0474
16A
Bushing, 2 in. NPSM x 3/4 in. NPT 1 512-0043
16B
Bushing, 2 in. NPSM x 1/4 in. NPT 1 512-0041
16C
Drain Valve 1 072-0019
16D
O-ring, 2 in. 2 513-0001
17 Warning Label 1 098-3870
18 U-nut, spring 5 103-0205
19 Screw #10-32 x 3/4 in. 2 061-0212
20 Switch Assembly 1 See Parts List - Pressure Switch
21 Nipple, 1/4 in. NPT x 2.5 in. lg 1 065-0005
22 Bleeder Tube 1 145-0495
23 Screw, 5/16-18 x 1/2 in. 1 059-0012
24 Pump Assembly (Less Flywheel) 040-0455
25 Compression Nut 2 058-0012
26 Transfer Tube 1 145-0724
27 Elbow, 90° 1/4 x 1/8 in. 1 068-0002
28 Check Valve 1 031-0020
29 Warning Label 2 098-2856
30 Bracket 1 114-0129
31 Elbow, 90° 3/4 x 3/4 in. 1 064-0032
32 Warning Label 1 098-3031
