Level Setup
Follow the instructions in the "initial
setup guidelines" section (page 6).
Zero the grade display precisely.
Turn the laser on and allow it to
level.
The aiming of the laser when
working dead-level is not
important.
In the event that a very long distance is required, the AS2 can be set-up in
the middle of the site, covering a total diameter of 2000 feet (610 meters)
using the R7 receiver. The AS2 MAGNUM can cover a 3300 foot (1000M)
diameter using the R8 receiver, or most brands/models of machine control
receivers.
Periodically check your setup against existing benchmarks or set and check
benchmarks of your own.
7
