12
Accessories
R5
e
Receiver
When your work takes you outdoors, a receiver is essential. No rotating
laser can be used outdoors in direct sunlight without a receiver, as it
would not be safe or legal to put out enough laser power to make the
rotating beam visible in those conditions. The R5e receiver has been
designed to provide excellent performance with the
L3
laser.
• 2" reception height
• Five channel LCD front display
• Selectable tone (hi, low, off)
• Accuracy: ± 1/16”
• 60 hour battery life
• 120º reception angle
• One year warranty
VM2 Vertical mount
The optional VM2 vertical mount allows the laser to be setup for vertical
applications (see pg. 10 for more information on on vertical setups). The
VM2 can be tripod mounted for vertical work and it can be fastened to a
wall using the molded-in holes.
NOTE: The laser beam must be rotating (not scanning) and the
rotation speed must be set to maximum when using a receiver.
