CD-212
PRO WELD
T
his technique, when equipment is set up properly,
is simple and easily mastered. The same power su
p-
ply is capable of welding many different sizes and
materials of fasteners. If you require assistance in
se
lecting the proper accessories, contact our cu
s-
tomer service department or your field represent
a-
tive.
7.0 POWER REQUIREMENTS
110 VOLT OPERATION
110 volt AC 60 H:
20 amps;
Circuit protection:
15 amp circuit breaker
(P
/N: 104
-
0020)
Integral 9 foot power cord
IF EXTENSION REQUIRED
Cable Length
110 Volt
12’
#16/3
25’
#16/3
30’
#14/
3
50
#12/3
8.0 SYSTEM SPECIFICATIONS
Weight:
26 Lbs.
Size:
9” W x 11 3/4” D x 8 1/2” H
22.9 cm W x 29.8 cm D x 21.6 cm H
Chassis:
14 Ga. Aluminum (Painted International
Orange)
Panel Controls:
Power
Voltage Controls
Weldable Materials:
Steel,
Stainless steel, Aluminum, Copper,
Brass, Zinc coated, Galvanized
Weldable Stud Diameter:
14 Ga. Through 1/4” Flanged
(Max W.
B. Dia. For AL=5/16” (1/4” thread)
Weld Rate:
12 per minute
Weld Voltage:
45-
200 VDC
Weld Mode:
Contact
Polarity:
Straight or Reverse
Power Required:
110 Volt AC 60 Hz 20 Amp
Circuit Protection:
15 Amp circuit
breaker
3AG 1 Amp 250 volt fuses
(2 on PC Board)
STANDARD GUN & CABLE SPECIFICATIONS
WELD GUN
-
LIGHT DUTY PRECISION
CD CON
TACT
Part Number:
300-
0100 B Collet Gun
300-
0101 Taper Tip Gun
Weight:
2 lbs. (not including cable)
( lbs. (including 25 ft
. #4 weld cable & 16
-4
SOW control cable)
Size:
6 1/2” x 5 3/4” x 2”
Weldable Stud Diameter:
14 Ga. Through 1/4” Flanged
Mate
rial:
High strength, impact resistant, glass fiber re
-
inforced polycarbonate
Integral Gun Cable Length:
25 feet
–
#4 AWG
Conn
ectors:
Male Camlok / 2 Pin Hubbell Male
Cables
Ground Cable:
(1) #4 x 15’
(P/N: 125
-
0100)
Page
3
