Pro-Weld CD-212 - Table of Contents

CD-212
PRO WELD
TABLE OF CONTENTS
1.0 INTRODUCTION 1
2.0 WARRANTY 1
3.0 UNPACKING YOUR UNIT 1
4.0 SUGGESTED SAFETY PRECAUTIONS 1
5.0 GENERA L DESCRIPTION 2
6.0 THE CD WELDING PROCESS 2
7.0 POWER REQUIREMENTS 3
8.0 SYSTEM SPECIFICATIONS 3
9.0 WELDING SYSTEM HOOK - UP 4
9.1 Straight Polarity 4
9.2 Reverse Polarity 5
10.0 SYSTEM OPERATION 6
11.0 GUN SET - UP 7
11.1 Standard 7
11.2 Installin g or Changing Collets or Chucks 8
11.3 For Weld Pins with Collet Protector 8
11.4 Template Adapter 9
11.5 Collet Protector wi th Blunt Leg 9
11.6 Parts List LD CD Handgun 11
12.0 WELDABLE MATERIAL COMBINATIONS 12
13.0 CAUSES OF POOR OR ERRATIC WELDS 13
14.0 TROUBLE SHOOTING POOR WELDS 13
15.0 ROUTINE WELDER MAINTENANCE 14
16.0 ASSEMBLY – CD - 212 CONTROLLER 15,16
16.1 PC Boar d Assembly Drawing 17
17. TROUBLE SHOOTING – ELECTRICAL 18
18.0 CHECK LIST CD - 212 SYSTEM P.N. 100 - 0112 20
19.0 CHECK LIST CD - 212 SYSTEM P.N. 100 - 0113 20
