CD-312
PRO WELD
T
his technique, when equipment is set up properly,
is simple and easily mastered. The same power su
p-
ply is capable of welding many different sizes and
materials of fasteners. If you require assistance in
se
lecting the proper accessories, contact our cu
s-
tomer service department or your field represent
a-
tive.
7.0 POWER REQUIREMENTS
110 VOLT OPERATION
110 volt AC 60 H:
25 amp service
Internal :
20 amp;
circuit breaker
(P/N: 104
-
0021)
Integral 9 foot power cord
IF EXTENSION REQUIRED
Cable Length
110 Volt
12’
#16/3
25’
#16/3
30’
#14/3
50
#12/3
8.0 SYSTEM SPECIFICATIONS
Weight:
48 Lbs.
Size:
8 1/2” W x 10” D x 16 1/2” H
21.6 cm W x 25.4 cm D x 42 cm H
Ch
assis:
16 Ga. Steel (Painted International Orange)
Panel Controls:
Power
Voltage Control
Weldable Materials:
Steel, Stainles
s steel, Aluminum, Copper,
Brass, Zinc coated, Galvanized
Weldable Stud Diameter:
12 Ga. Through 3/8” Weld Base
(Max W.B. Dia.
For AL=5/16” {1/4” thread})
Weld Rate:
24 per minute 5/16”
Weld Voltage:
45-
185 VDC
Capacitance:
88,000 uF nominal
Weld Mode:
Contact
Polarity:
Straight or Reverse
Power Required:
110 Volt AC 60 Hz 25 Amp
Int
ernal Fusing:
20 Amp Circuit Breaker
3AG 1 Amp 250 volt (2 on PC board)
STANDARD GUN & CABLE SPECIFICATIONS
WELD GUN
-
LIGHT DUTY PRECISION
CD CONTACT
Part Number:
300-
0100 B Collet Gun
300-
0101 Taper Tip Gun
Weight:
2 lbs. (not including cable)
(
lbs. (including 25 ft. #4 weld cable & 16
-4
SOW control cable)
Size:
6 1/2” x 5 3/4” x 2”
Weldable Stud Diameter:
14 Ga. Thr
ough 1/4” Flanged
Material:
High strength, impact resistant, glass fiber re
-
inforced polycarbonate
Integral Gun Cable Length:
25 feet
–
#4 AWG
Connectors:
Male Camlok / 2 Pin Hubbell Male
Cables
Ground Cable:
(1) #4 x 15’
(P/N: 125
-
0100)
PAGE 3
