Pro-Weld CD-312 - 16.0 ASSEMBLY CD-312 CONTROLLER

CD-312
PRO WELD
ITEM DESCRIPTION PART NUMBER
1 Knob 102-0060
1A Charge Pot 25K 111-0001
2 SCR Mounting 124-0026
3 Main SCR 108-0001
4 Buss Bar 124-0037
5 Buss Bar 124-0036
6 Capacitor 106-0023
7 Chassis 101-0016
Figure 16 Parts List
16.0 ASSEMBLY CD - 312 CONTROLLER (see Figure 15,16, & 17)
1
2
3
4
5
6
7
PAGE 17
1A
