CD-312
PRO WELD
LIST OF FIGURES
1 CD CONTACT PROCESS 2
2 STRAIGHT POLARITY HOOK- UP 4
3 REVERSE POLARITY HOOK - UP 5
4 CUPHEAD PIN HOOK - UP 6
5 FRONT PANEL LAYOUT 7
6 STANDARD GUN SETUP 9
7 COLLET PROTECTOR SETUP 10
8 TEMPLATE ADAPTER GUN SETUP 11
9 COLLET PROTECTOR/ BLUNT LEG SETUP 11
10 LIGHT DUTY CD GUN 13
11 HOT WELD 16
12 COLD WELD 16
13 ARC BLOW 17
14 WELD WITHOUT FOOTPIECE 17
15 G OOD WELD 17
16 PARTS LIST 18
17 PARTS LIST (continued) 19
18 PARTS LIST (continued) 20
19 PC BOARD 21
