Zelos™ 48-Inch Gas Catamaran
Rudder Installation
1. Installtherudderinthemountusing2screws
and2locknutsasshown.
2. Connectthetubefromthebackoftheboatto
thebarbedfittingonthetopoftherudder.
Propeller Installation
1. Correctlyalignthepropellerwiththedrivedog
onthepropshaft.
2. Tightenthenutonthepropshaft.
3. Disassembleinreverseorder.
Tip:Propellerbalancingcanaddseveralmphto
topspeedandreducevibration.Thereareseveral
differentpropellerbalancingtoolsavailable.Read
theinstructionsthataccompanythepropeller
balancingtool,asremovingmaterialfromthe
correctpartofthepropelleriscrucial.
Boat Stand Assembly
1. Attachthesidestandpiecestotheendpiecesas
shown.
2. UsemediumCAorepoxyadhesivetosecurethe
sidestandtotheends.
3. Allowtheadhesivetodrybeforeplacingyourboat
onthestand.
Canopy Removal
1. Loosenthe4screwslocatedateach
cornerofthecanopy.
2. Removethecanopyfromthehullstarting
withthe2rearscrews.Ensurethatthe4
screwshavedisengagedfromtheirbases
beforeliftingthecanopycarefully.
4
EN

