PROCEED AVP - Command Strings

AVP RS-232 Quick Guide Page 7
Command Strings
The AVP command strings are hexadecimal format. When programming the strings please follow the
guidelines of the control system being used for hexadecimal data.
Hexadecimal data is a series of numbers and letters that make up a byte. All command strings listed
here are shown with spaces between the bytes of data but the spaces are not part of the command
needed. Each control system will specify a separator to be used between bytes or a method to
identify the byte as hex. Please refer to the control system manual for proper sting byte separation
and hex identification.
Examples
Crestron requires a \x in front of each section of the command to see the value as HEX. Without the
\x the AVP will not respond to the command.
AVP OPERATE \x02\x02\x29\xBE\xC0
Action Action Description Complete String
Zone selection
BOTH Path Direct Input select acts on both MAIN and REMOTE zones 02 02 28 7E 01
MAIN Path Direct Input select acts on MAIN ZONE 02 02 26 BA 80
PATH Toggles between MAIN / REMOTE / BOTH paths on the AVP 02 02 0F 64 41
REMOTE Path
Direct
Input select acts on REMOTE ZONE 02 02 27 7A 41
Video Sources
Disc1 Disc 1 Source Selection 02 02 04 A3 00
Next Video source NEXT VIDEO Source Selection (Remote Command) 02 02 5A 5B 81
Previous Video
Source
Previous Video Selection (Remote Command) 02 02 4B 57 41
Satellite SAT Source Selection 02 02 01 A0 C0
TV / aux TV / AUX Source Selection 02 02 0D A5 C0
Vcr1 VCR1 Source Selection 02 02 0C 65 01
Vcr2 / disc2 VCR2 / Disc 2 Source Selection 02 02 14 6F 01
Audio Sources
Aux AUX Source Selection 02 02 15 AF C0
CD CD Source Selection 02 02 02 A1 80
MORE Toggles through the assigned MORE inputs. 02 02 06 62 81
MORE input AUX1 MORE input AUX1 Source Selection 02 02 5B 9B 40
MORE input AUX2 MORE input AUX2 Source Selection 02 02 5C 59 01
MORE input AUX3 MORE input AUX3 Source Selection 02 02 5D 99 C0
MORE input AUX4 MORE input AUX4 Source Selection 02 02 5E 98 80
