80
Specifications
■ Frequency response: 20 Hz – 20 kHz, +0dB, –0.2dB
■ Total harmonic distortion: 0.005% @ 1 kHz, A-weighted
■
Maximum output (XLR): 10 V rms
■ Maximum output (RCA): 5 V rms
■ Dynamic range: 100 dB (or better)
■ Signal to noise ratio (balanced outputs): 105 dB (ref: 0 dB output)
■ Channel separation: better than 100 dB
■ Analog filter: Bessel-tuned, linear phase to 40 kHz
■ Low-level linearity: deviation less than 1 dB to -90 dB FS
(1 kHz, 20 bit data, 80 kHz measurement bandwidth)
■ Volume range: 126 steps
■ Volume resolution: 0.5 dB steps above 16 in display,
gradually increasing step size at lower levels
■ Digital inputs:6 S/PDIF electrical on RCA
2 S/PDIF electrical on BNC
1 AES/EBU electrical
2 each EIAJ optical
■ RF Demodulator input: Digital Input 11 (w/opt. RF demodulator card)
■ Digital input impedance:75Ω (S/PDIF electrical)
110Ω (AES/EBU electrical)
■ Other inputs: 6 channel PAV analog pass-through
■ Digital output: 1 RCA (S/PDIF) on remote zone card
■ Digital output impedance:75Ω (S/PDIF electrical)
■ Main analog outputs: 6 balanced outputs
6 single-ended outputs
■ Analog output impedance:10Ω
■ Available trigger current: 80 mA per outlet
■ Power consumption: less than 70 W
■ Mains voltage: 100V, 120V, 200V, 230V, 240V,
factory set for destination country only
■ Mains frequency: 50 or 60 Hz,
factory set for destination country only
■ Overall dimensions: See “Dimensions”
■ Shipping weight: 34 lbs. (15.5 kg)
For more information, see your Proceed dealer, or contact:
Madrigal Audio Laboratories, Inc., P.O. Box 781,
2081 South Main Street, Middletown, Connecticut 06457 USA
Telephone (860) 346-0896 FAX (860) 346-1540
If purchased in the United States or Canada, the warranty on this Proceed
product is owner-transferable. If your product requires service, you must obtain
a Return Authorization before shipping it to Madrigal. Madrigal reserves the
right to repack any product which arrives improperly packed for shipment and
to charge the owner for the required packing material. For warranty
information and conditions on products purchased in other countries, contact
your local dealer or distributor.
