• Insert the weight (7) into the guides with the black rubber part forward-facing
first one side of the weight then the other as shown below.
• Rotate the weight (7) so that the black rubber part faces down, then fix it with
the two knurled screws (11).
• Connect the Temperature Controller as described in the separate instruction
manual.
• Level the apparatus using the included spirit level. To do so, place the spirit
level and adjust the levelling feet (10) until the Proceq ZAA 2300 levels
perfectly. The plate must be firmly in place.
To protect persons and the apparatus, proper care must be taken when
lifting or carrying it. It is recommended to hold and carry the Proceq ZAA
2300 on both sides of the housing. Always remove the glass plate / heating
plate before lifting or tilting the device.
