PROCESS
OUTLET 3
INLET 3
PROCESS
INLET 1
PROCESS
OUTLET 1
PROCESS
PURGE OUTLET OR DRAIN
1/4" PILLAR S300 FITTING
362
14.25
51
2.00
200
7.88
2.00
51
1.13
29
.85
22
111
4.38
LABEL
HIGH VOLTAGE
MODEL NO. LABEL
213
8.37
±13508
±.520.0
±131778
±.570.0
10.00
254
2.13
54
10
.40
(4 PLACES)
INCHES
[mm]
MATERIAL:
PROCESS TECHNOLOGY
OF
BY: MJM
APPROVAL INFORMATION:
®
7010 LINDSAY DR, MENTOR OH USA
WITHOUT THE PERMISSION OF PROCESS TECHNOLOGY.
ITEM:
A
SIZE:
(P) 440-974-1300 (F) 440-974-9561
CONFIDENTIAL INFORMATION AND MAY NOT BE REPRODUCED IN ANY WAY
PROJECTION
SCALE:
WWW.PROCESS-TECHNOLOGY.COM
THIS DRAWING IS THE PROPERTY OF PROCESS TECHNOLOGY. IT CONTAINS
TOLERANCING PER ASME Y14.5M
DRAWING No.
NONE
1
PAGE:
5
UNLESS NOTED TOLERANCES ARE:
SECONDARY UNIT FOR REFERENCE ONLY
3rd ANGLE
DATE: 12/04/14
INTERPRET GEOMETRIC
DIMENSIONING AND
62-0071-
0.00 =
FACILITIES: SHC-1.4-61RQH-R-0070
CONTROLLED DOCUMENT LOCATIONS:
DRAWN BY: DLS
1
0.000 =
ANGLES =
DESCRIPTION:
DATE: 04/12/17
.06
.030
1
.340 [9] (14AWG,
GRAY PVC, 90C, UL RATED)
CONNECTOR (PART # 788153-2)
TE CONNECTIVITY / AMP PLUG
POWER CONNECTION
.310 [7] (20AWG,
GRAY PVC, 105C, UL RATED)
CONTACT HOUSING (PART # 1688353)
POWER CABLE:
DB9 PLUG CONNECTOR WITH PHOENIX
SIGNAL CONNECTION
SIGNAL CABLE:
SERIAL NUMBER
LABEL
32
1.25
194
7.64
3.88
98
235
9.25
INLET 2
PROCESS
OUTLET 4
PROCESS
OUTLET 2
PROCESS
INLET 4
PROCESS
PURGE INLET
1/4" PILLAR S300
FITTING
2.00
51
29
1.13
51
2.00
7.88
200
1.25
32
111
4.38
REV BY DATE DESCRIPTION
5 MJM 04/12/17
UPDATED RTD DESIGN PER LAM PR 647206 AND CMR
142.
4 TRJ 07/27/15 CHANGED PROCESS LABELS PER DCR 304
3 DLS 04/23/15 ADDED HOUSING PURGE/DRAIN OPTION DETAILS
NOTES:
HEATER SPECIFICATIONS: 1400W @ 480V, 1PH, 50/60Hz, 2.9 FLA 1.
@ 480V.
THERMAL CUT-OFF DEVICE (BIMETALLIC SWITCH) IS RATED FOR 2.
2.6A @ 120VAC OR 4A @ 24 VDC AND OPENS AT 194ºF [90ºC].
TEMPERATURE SENSORS (2 EA) ARE 100 OHM, 3-WIRE RTDs.3.
ALL WETTED COMPONENTS ARE PFA.4.
MAXIMUM PRESSURE RATING IS 45 PSI [3.1 BAR] AT 60ºC AND 40 5.
PSI [2.7 BAR] AT 80ºC.
EXTERNAL HOUSING MATERIAL IS FLAME-RETARDANT 6.
POLYPROPYLENE.
HEATER CAN BE MOUNTED VERTICALLY OR HORIZONTALLY. IF 7.
PURGE/DRAIN OPTION USED, HEATER MUST BE ORIENTED WITH
THE PURGE OUTLET / DRAIN FITTING AT THE LOWEST POINT.
APPROXIMATE WEIGHT IS 28 lbs [12.7 kg].8.
PROCESS INLET CONNECTIONS ARE 1/4" NIPPON PILLAR SUPER 9.
300 FITTINGS.
PROCESS OUTLET CONNECTIONS ARE 1/8" NIPPON PILLAR 10.
SUPER 300 FITTINGS.
IF UNIT IS PURGED, PURGE OUTLET MUST BE CONNECTED TO 11.
THE PROPER CHEMICAL DRAIN DEPENDING ON PROCESS
CHEMISTRY USED.
PURGE IN: N2 FLOW 1-2 SCFH [28-57 LPH], MAX PURGE INLET 12.
PRESSURE OF 2 PSIG [13.8 kPA]
To Next Page
