5486411070 Spare Parts List - Legend GT
Wand - Tri Jet -Optional
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
- 86285520 - WAND, TJW (9502) PC COMPLETE
- 86285510 - WAND, TJW, (95015) CUBXL COMPLETE
- 86285530 - WAND, TJW, (9503) PC COMPLETE
1 86005580 1 NIPPLE, 1/4 FPT QD
2 86177860 1 CONN, 1/4P X 11/16-16M
3 86195570 2 WASHER, NYLON
4 86193490 1 STRAINER, JET 50MESH
5 86177870 1 CONN, 1/4FP, 11/16-16R BR
6 86247680 1 NIPPLE, 1/4 HEX
7 86280020 1 SLEEVE, WD HDL 9.5
8 86194650 1 TRIGGER, WD VLV
9 86192030 3 SCR, CAP 10-32X 1-1/4 SOCH
10 86270990 3 NUT, 10-32 HEX NYLOCK SS
11 86174120 1 ASSY, EXTRCTR VLV
12 86177650 1 CONN, 1/4P X 1/4T BR
13 86183970 1 HOSE, 3/16X49 (1/8P X 1/4FT)
14 86265730 3 TIE, CABLE 8” WHT
15 86273310 1 SCR, CAP 1/4-20 X 1-1/4 SOC
16 86198160 1 HOLD DOWN, WD HDL
17 86182840 1 BODY, WD HDL
18A 86194410 3 TIP, SPRY 9502X1/8P SST 89233
18B 86194400 3 TIP, SPRY 9501X1/8P SST 89232
18C 86194520 3 TIP, SPRY 9503X1/8P SST 89234
19 86274290 2 SCR, 10-32 X 3/8 PPHMS SS
20 86279470 2 WASHER, #10 SPLIT LOCK
21 86270800 2 NUT, 10-32 HEX SS
22 86187700 1 MANIFOLD, WD TRI-JET
23 86190180 2 PLUG, 1/8 SOCHD BR
24 86183160 1 HOLDER, VLV STEM-EXTRCTR VL
25 86189520 1 O-RING, .551 ID .691 OD
26 86192410 1 SEAT, EXTRCTR VLV
27 86193360 1 STEM, EXTRCT VLV
28 86174500 1 BACK-UP, .250DIA
29 86189510 1 O-RING, .114ID .254OD
30 86193200 1 SPRING, EXTRCTR VLV
31 86179020 1 BODY, EXTRCTR VLV
- 86179020 - DECAL, WD HD
- 86186160 - KIT, REP-WD VLV
INCLUDES PARTS
24-30
