Prochem LGTPC - Hose Diagram

3886411070 Spare Parts List - Legend GT
Hose Diagram
REGULATOR
SOLUTION OUTLET
MANIFOLD
86282410 (72")
SUPPLIED WITH ENGINE
86282770 (LOOM)
LUBE CUP ON
FRAME
86312330 (28")
HEAT
EXCHANGER
86280520 (31")
86313610 (61")
86185150 (15")
86183580 (54")
86040800 (88")
86184120 (52")
86183700 (19")
86282880 (29")
86282920 (42")
86184400 (26")
86183300 (9")
86313670 (104")
86311490 (3")
86410750 (42")
86048980 (36")
86184120 (52")
86328940 (51")
86280080 (46")
86312750 (23")
86280470 (24")
86185150 (15")
86183700 (19")
86040800 (88")
86313670 (104")
SOLUTION/CHEMICAL
PUMP
86176990 (1)
86181300
86193410
VACUUM
BLOWER
TO WASTE TANK
SIDE PANEL
CHEMICAL
BOTTLE
