Prochem LGTPC - Page 65

486411070 Spare Parts List - Legend GT
Frame
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
1 86270330 26 FLATWASHER, 1/4
2 86278830 17 WASHER, 5/16 FLAT PLTD
3 86177640 1 CONN, 1/8P X 1/4POLY BR
4 86178700 1 CUP, OIL FILL 1/8P
5 86194670 1 TRIM, FLEX, TM
6 86161800 4 LATCH, CONCEALED KEEPER
7 86005680 7 NUT, 1/4-20 HEX NYLOCK
8 86274750 15 SCR, 1/4-20 X 3/4 HHCS
9 86006760 4 SCR, 5/16-18 X 3/4 HHCS GR5
10 86274910 2 SCR, 5/16-18 X 1.25 HHCS GR5
11 86275460 5 SCR, 1/4-20 X 3/4 BHCS
12 86275570 4 SCR, 1/4-20 X 1.00 HHCS GR5
13 86233410 1 CLAMP, 3/4 DIA CUSHION .406 DIA
14 86238500 2 GROMMET, 1.703IDX2.5ODX.125GRV
15 86279130 15 WASHER, 5/16 SPLIT LOCK
16 86279400 5 WASHER, 1/4 SPLIT LOCK BLK
17 86010780 15 WASHER, 1/4 SPLIT LOCK
18 86279520 5 WASHER, 1/4 ID FLAT BLK
19 86313920 1 GUARD, BELT, FRONT
20 86314700 3 CLAMP, CABLE,1-3/4 "P"CUSHION
21 86177430 1 CLMP, 1-1/16 ID X 3/8 BLT
22 86191800 4 RIVET, 5/32 OD X .188-.250 GL AL
23 86191810 8 RIVET, 5/32 OD X .251-.375 GL AL
24 86309130 1 PNL, LOWER FRONT
25A 86409230 1 LABEL, LOWER FRONT PNL
25B 86309420 1 LABEL, LOWER FRONT PNL
1.001-162.0 ONLY
26 86310020 1 BRKT, HE SUPT
27A 86412340 1 HOOD, TOP
27B 86310110 1 BRKT, CENTER HOOD
1.001-162.0 ONLY
28A 86412350 1 HOOD, LEFT
28B 86310120 1 PNL, LEFT HOOD
1.001-162.0 ONLY
29A 86412360 1 HOOD, RIGHT
29B 86310130 1 HOOD, RIGHT
1.001-162.0 ONLY
30 86393780 1 ASSEMBLY, SM SHT MTL FRAME
31 86310470 1 GUARD, BELT
32 86310810 1 BRKT, FRAME STIFFENER
33 86369940 1 PNL, REAR ENGINE SUPT
34 86313750 1 GUARD, BELT, LOWER REAR
35 86313910 1 BRKT, LEFT FRAME STIFFENER
36 86315490 4 GASKET, VIBE DAMPNR
37 86373930 4 RIVET, 5/32 X.376-.500GL POP AL
38 86369930 2 BRACKET, REAR STABILITY
39 86006750 11 SCREW 5/16-18 X 1"HHCSGR5PLT NP
40 86005750 6 NUT, 5/16-18 HEX NYLOCK STL GR2 ZNPLT
41 86394280 1 SHIELD, LGT EXHAUST TUBE HEAT
