1086411070 Spare Parts List - Legend GT
Control Panel - Upper 2
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
1 86270330 5 FLATWASHER, 1/4
2 86181300 2 FTTG, BRB 1/8P X 5/16H
3 86181170 1 FLOWMETER 1/8FP
4 86193750 1 SW, RTRY NON-ILLUM TM
5 86176120 1 CABLE, CHOKE
6 86181930 1 GAUGE, 0-1200 PSI
BRKT 86175680
INCLUDED
7 86181950 1 GAUGE, VACUUM, 15" HG
BRKT 86175680
INCLUDED
8 86181960 1 GAUGE, TEMP, DATCON
9 86005680 6 NUT, 1/4-20 HEX NYLOCK
10 86270920 4 NUT, 6-32 HEX NYLOCK SS
11 86270990 4 NUT, 10-32 HEX NYLOCK SS
12 86273820 3 SCR, 1/4-20 X 1.25 HHCS SS
13 86274290 2 SCR, 10-32 X 3/8 PPHMS SS
14 86274750 2 SCR, 1/4-20 X 3/4 HHCS
15 86233410 3 CLAMP, 3/4 DIA CUSHION .406 DIA
16 86279190 4 WASHER, #10 X .40 FLAT
17 86010780 2 WASHER, 1/4 SPLIT LOCK
18 86279470 2 WASHER, #10 SPLIT LOCK
19 86017360 1 BRKT, FLOW METER
20 86177540 1 CNTRL, THRTL, CLR/CLNR
21 86409250 1 LABEL, CONTROL PANEL, PC
22 86412370 1 PANEL, FRONT, LGT, PC
STANDARD FOR
10011190
- 86309910 1 PANEL, CONTROL, LGT, PC
STANDARD FOR
10011620
- 86335040 1 ASSY, CONTROL PNL, LGT VT
STANDARD FOR
10011380 AND
10011410
23 86409260 1 LABEL, FRNT HD, LGT, PC
24 86312880 1 PNL, GRILLE, GT
25 86409270 1 LABEL, CHEM PNL, GT
26 86358480 2 SPACER, BEAUTY RING
27 86399570 1 HARNESS, LEGEND GT WIRING NOT SHOWN
