1286411070 Spare Parts List - Legend GT
Engine
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
1 86277830 4 SCR, 3/8-16 x 2" HXHD
2 86273440 7 SCR, MACH 5/16-18 X 1" GR8
3 86270830 4 NUT, 5/16-18 HEX NYLOCK SS
4 86176990 1 CLAMP, HOSE #4 SST
5 86183600 1 HOS, 3/8 X 10 (3/8P X 1/2T)
6 86190550 1 PLUG, 1/2T
7 86185350 1 HUB, P1 X 1-1/8
8 86049230 2 KEY, 1/4 SQ X 1.88
9 86182290 1 GSKT, EXH, KUB, D902/WG972
10 86136280 4 NUT, M8 HEX
11 86270990 1 NUT, 10-32 HEX NYLOCK SS
12 86005770 4 NUT, 3/8-16 HEX NYLOCK
13 86273980 1 SCR, 10-32 X 3/4 PPHMS SS
14 86277930 1 SCR, 1/4-20 X 3/8 SSSCU DL
15 86136640 1 SCR, M8 X 20 HHMS
16 86006750 4 SCR, 5/16-18 X 1"HHCSGR5PLT NP
17 86277890 1 SCR, M5 - 8 X 25MM STL, ZNC
18 86277680 3 SCR, 1/4-20 X 1-1/4 HXHD GR8
19 86233410 2 CLAMP, 3/4 DIA CUSHION .406 DIA
20 86279130 4 WASHER, 5/16 X .583 X .078 SPL STL ZNPLT
21 86010740 1 WASHER, 1/4 X 3/4 FLAT
22 86270330 1 FLATWASHER, 1/4
23 86279130 5 WASHER, 5/16 X .583 X .078 SPLSTLZNPLT
24 86278830 4 WASHER, 5/16 X .875 X .083 FLT STL ZNPLT
25 86279510 8 WASHER, 3/8 X 1 FLAT NP
26 86182730 2 GSKT, EXHST, KHLR 25HP
27 86191280 1 PULLEY, 1B36SH
28 86185400 1 HUB, SH1
29 86177130 1 CLAMP, CABLE, THROT/CHOKE
30 86310480 1 ENGINE, KOHLER 23HP
31 86311440 1 TUBE, EXHAUST, KOHLER 23HP
32 86313550 1 PULLEY, 2TA62
33 86315860 1 FILTER, FUEL KOH 23HP
34 86315870 1 ELEMENT, AIR FILTER KOH 23HP
35 86315840 1 PRE-CLEANER, KOHLER 23 HP
36 86186320 1 KOH FLTR, OIL #1205001-S
37 86315850 1 STARTER, SOLENOID SHIFT KOH 23HP
38 86186360 2 KOH SPK PLG #1213202-S
