2086411070 Spare Parts List - Legend GT
Heat Exchanger
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
1 86270330 17 FLATWASHER, 1/4
2 86313730 1 PLATE, HEATER CORE COVER
3 86180220 6 ELL, 3/8 BR
4 86394270 1 GASKET, LGT 3RD CORE HE
5 86181330 1 FTTG, BRB 3/8PX1/2H BR
6 86310660 1 PNL, DIVERTER
7 86177700 4 CONN, 3/8P X 1/2T BR
8 86181400 1 FTTG, BRB 3/8P x 5/8H BR
9 86308930 1 GASKET, HEATER CORE COVER
10 86182190 6 GROM, 1/2 ID X 1-1/8 OD
11 86006740 6 SCR, 3/8-16 X 1.00 HHCS GR5
12 86274750 17 SCR, 1/4-20 X 3/4 HHCS
13 86010780 17 WASHER, 1/4 SPLIT LOCK
14 86010790 6 WASHER, 3/8 SPLIT LOCK
15 86279510 6 WASHER, 3/8 X 1 FLAT NP
16 86043150 2 ASSEMBLY, HEATER CORE SS
17 86177260 1 CLMP,HOS#10 9/16MIN 1-1/
18 86318840 1 ASSY, HEATER CORE COPPER, GT
19 86308840 1 HSG, VAC HE BOX
20 86308920 1 PLATE, HEATER CORE COVER
21 86386920 1 CLAMP, HOSE #06 3/8"-7/8" X 1/2"
