2486411070 Spare Parts List - Legend GT
Solution Outlet
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
1 86270330 6 FLATWASHER, 1/4
2 86188080 1 NIP,3/8 HX BR
3 86188130 1 NIPPLE, 3/8M X 1/4M
4 86190180 1 PLG, 1/8 SOCHD BR
5 86180210 1 ELL, ST 3/8 BR
6 86180220 1 ELL, 3/8 BR
7 86394840 1 CROSS, 3/8 FPT BRASS
8 86180360 2 ELL, 1/8P X 1/4T BR
9 86180420 1 ELL, 1/8P X 1/4T 45 DEG
10 86180450 1 ELL, 3/8P X 1/2T 45 DEG. BR
11 86193490 1 STRNR, JET 50MESH
12 86177860 1 CONN, 1/4P X 11/16-16M
13 86002450 1 COUPLER, 1/4 QD
14 86002820 1 CAP, NOZZLE
15 86197440 1 ELBOW, 3/8MPT X 1/4 FPT
16 86270770 3 NUT, 1/4-20 HEX
17 86273850 3 SCR, 1/4-20 X 2.00 HHCS SS
18 86010780 3 WASHER, 1/4 SPLIT LOCK
19 86189190 1 ORIFICE, BYPASS 4916 20 ZEEMS
20 86173580 1 ADPTR, HOSE BYPASS
21 86180670 1 ELL, 1/8 FEMALE NPT, BR
22 86311640 1 ASSY, SOLUTION MANIFOLD, 6.63”
23 86312630 1 NIPPLE, 3/8 X 2 BR
24 86192240 1 SCRN, MESH W/O-RING, SOL MNFLD INCLUDES 25-26
25 86189260 1 O-RING
26 86192210 1 SCREEN, CHECK VALVE
27 86195030 1 VALVE, CHECK INCLUDES 28-34
28 86189230 1 O-RING
29 86192390 1 SEAT, CHK VLV ASSY
30 86194250 1 TEFLON SEAT
31 86190910 1 POPPET, CHK VLV ASSY
32 86193260 1 SPRING
33 86189270 1 O-RING, 7/8 ID 1-1/16 OD
34 86176350 1 CAP
35 86175920 1 BUSH,3/8x1/8 BR
36 86192490 1 SENDER,TEMP 140-320DEG
