2686411070 Spare Parts List - Legend GT
Water Box
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
1 86273410 2 SCR, CAP 1/4-20 X 8 HXHD
2 86270330 12 FLATWASHER, 1/4
3 86233110 1 CLAMP, 1.0" WORM GEAR
4 86177260 2 CLMP,HOS#10 9/16MIN 1-1/
5 86180230 1 ELL, STREET 1/2 45 DEG
6 86188180 2 NIP, 1/2 CL
7 - - OPEN
8 86180250 1 ELL, 1/2 BR
9 86176400 1 CAP, WATER BOX
10 86177660 1 CONN, 1/8P X 1/4T
11 86181360 2 FTTG, BRB 1/2P X 5/8H BR
12 86181370 1 FTTG, BRB 1/2P x 3/4H BR
13 86193440 2 STRAINER, SUC END 1/2FP
14 86195320 1 VLV, TEMP REL 165DEG
15 86195060 1 VALVE, FLOAT, TM
16 86348200 1 BALL, 4" DIA X 5" L, WHITE FLOAT
17 86181150 1 ROD, FLOAT 1/4-20 X 6" SS
18 86187820 1 MOLDING, WATER BOX
19 86317520 1 EL, STRT 1/2MP X 1/2FP W/ 1/8FP
20 86270770 2 NUT, 1/4-20 HEX
21 86005680 6 NUT, 1/4-20 HEX NYLOCK
22 86274750 4 SCR, 1/4-20 X 3/4 HHCS PLTD
23 86308940 1 BRKT, WTR BOX HOLDDOWN
24 86309000 1 BRKT, WTR BOX MTG
25 86180360 1 ELL, 1/8P X 1/4T BR
26 86010660 2 WASHER 1/4 LOCK EXT STAR SS
27 86192380 1 SEAT FLOAT VALVE TM
28 86189010 1 NUT, FLOAT VALVE
