3086411070 Spare Parts List - Legend GT
100 Gallon Waste Tank
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
- 98408780 1 KIT, WASTE TANK 100G LGT/BGT PC COMPLETE
1 86190530 2 PLUG, 1-1/4 HXHD PVC
2 86180340 2 ELL, 1/4P X 1/4T BR
3 86193540 1 STRNR, WST TNK, RECT, 1.5
4 86186860 2 LATCH, DRAW 2-7/8 SST
5 86043190 1 STRAINER BOWL, AVENGER 450
6 86005810 8 NUT, 1/4-20 HEX NYLOCK SS
7 86273020 8 RIVET, 3/16 OD X 5/8 AL
8 86273810 4 SCR, 1/4-20 X 1 HHCS SS
9 86010630 8 WASHER, 1/4 X 5/8 FLAT SS
10 86193870 1 ASSY, LVL SENS SHTOF SW
11 86202240 4 WASHER, SEAL 1/4 X 1 OD SS
12 86325770 1 GASKET, 100G LID WST TNK
13 86318560 2 GASKET, VAC OUTLET
14 86410180 1 TANK, WASTE, 100G PC
15 86410170 1 LID, 100G WST TNK, PC
16 86412520 1 OUTLET, VACUUM, 2-7/8", PC, GRY
17 86412530 1 INLET, 2-1/2" VACUUM, PC, GRY
18 86323700 1 GASKET, VAC INLET
19 86177010 1 CLAMP, HOSE #48
20 86272720 1 PLG, 1/4 SOCHD BRASS
21 86415330 1 ELBOW, Ø3.50 OD X 53°
22 86277000 4 SCREW, 1/4-20 X 1.5 CARR SS
- 86264850 - ADH,GSKT (ADHESIVE)
